All-in-one Vacuum Concentrator
Ningbo Scientz Freeze Drying Equipment Co., Ltd. is one of the most experienced manufacturers and suppliers of all-in-one vacuum concentrator in China. Please rest assured to wholesale high quality all-in-one vacuum concentrator made in China here from our factory. We also accept customized orders.
The SCIENTZ-1LS is a compact all-in-one vacuum concentrator combining centrifugal force, vacuum and heating into a single integrated unit. This all-in-one vacuum concentrator is ideal for concentrating small to mid-volume biological, chemical, and analytical samples without requiring separate vacuum pumps or cold traps. Because it integrates the rotor, vacuum chamber, cold trap, and condensate management into one chassis, the all-in-one vacuum concentrator simplifies setup, minimizes footprint, and improves operational convenience. Choose the all-in-one vacuum concentrator solution when you want a compact, efficient, self-contained concentrator for your lab workflow.
Key Features
Integrated design
the all-in-one vacuum concentrator houses the centrifuge motor, vacuum chamber, cold trap and condensate trap in a unified architecture, eliminating external ducting or accessories.
Magnetic levitation drive & sealed chamber
low vibration and excellent vacuum sealing help maintain sample integrity-core to a robust all-in-one vacuum concentrator.
Rotor flexibility
supports multiple rotor types (e.g. 2 mL, 15 mL, 50 mL, 96-well plate) to accommodate a wide range of sample formats in one all-in-one vacuum concentrator platform.
Cold-trap & water trap built-in
integrated cold trap (≤ –45 °C) and water trap protect the vacuum pump and streamline maintenance for the all-in-one vacuum concentrator.
User-friendly automation
one-key start, adjustable vacuum, timing control, optional temperature settings-all managed within the all-in-one vacuum concentrator interface.
Technical Specifications
|
SCIENTZ-1LS |
||||
|
Function |
Numeric Value |
|||
|
Maximum Speed |
2000 r/min |
|||
|
Temperature Range |
Room Temperature: ~70℃ |
|||
|
Maximum Timer Duration |
1-99 hor 1-59 min |
|||
|
Cold Trap Temperature |
<-45℃ |
|||
|
Dimensions |
540(L)x445(W)x950(H) |
|||
|
Weight |
100 kg |
|||
|
Power Supply |
220 V/50 Hz |
|||
|
Input Power |
2.5 kW |
|||
|
Standard Rotor |
15 ml (Φ18x20/Φ16x20)/2 ml (Φ11x46) |
|||
|
Optional Rotor Types |
2 ml (Φ11x80) |
15 ml (Φ16x46) |
15 ml (Φ19.5x36) |
50 ml (Φ33x10) |
|
2×96-Well Microplates |
2×48-Well Microplates |
|||
Applications
- Biotechnology & Molecular Biology:
concentration of DNA/RNA, proteins, metabolites, solvents-ideal tasks for an all-in-one vacuum concentrator.
- Analytical Chemistry & Sample Prep:
concentrate trace samples prior to HPLC, GC, MS analysis.
- Microbiology / Microfluidics:
concentrate culture supernatants or small volume media with minimal loss.
- Clinical / Diagnostic Labs:
sample concentration in limited footprint settings.
- Environmental Analysis:
concentrate contaminants or extracts in aqueous or organic media.
Why Choose the SCIENTZ?
- Truly integrated solution:
unlike traditional setups needing separate vacuum pumps and cold traps, the SCIENTZ-1LS is a complete all-in-one vacuum concentrator.
- Low maintenance & compact:
built-in traps and sealed rotor reduce plumbing and maintenance concerns.
- Rotors flexibility:
support for multiple rotor types for broad application coverage in one all-in-one vacuum concentrator system.
- Operational safety & sample protection:
magnetic levitation drive and automatic vacuum release upon power interruption help safeguard samples.
- Strong brand & ecosystem:
part of the SCIENTZ portfolio; compatible with SCIENTZ's freeze-dry systems for workflow integration.
Technical Support and Customization
Turnkey services:
includes installation, commissioning, and user training.
Warranty & support:
standard 12-month warranty; spare parts and calibration services available.
Customization:
optional cooling upgrades (lower trap temp), rotor customization, dual condensing modules, interface options, voltage variants, etc.
Optional modules:
sample temperature probes, remote monitoring / SCADA integration, enhanced vacuum control modules.
Contact Now
For a compact, high-functionality all-in-one vacuum concentrator, the SCIENTZ-1LS delivers simplicity, reliability, and performance. Contact us for datasheets, quotations, or customization options.
