Laboratory T-frame Freeze Drye
Ningbo Scientz Freeze Drying Equipment Co., Ltd. is one of the most experienced manufacturers and suppliers of laboratory t-frame freeze drye in China. Please rest assured to wholesale high quality laboratory t-frame freeze drye made in China here from our factory. We also accept customized orders.
Key Features
24 Independent Sealing Valves
Each hanger has its own rubber sealing valve-allowing sample isolation, flexibility, and minimal cross-interference-typical in a Laboratory T-frame freeze dryer.
Independent Material Lines
Each line is isolated to avoid cross contamination during freeze-drying-a design detail differentiating the SCIENTZ-25TK as a higher-end Laboratory T-frame freeze dryer.
Low-temperature capability
Standard cold trap reaches –56 °C (no load); optional upgrade to –80 °C supported-necessary for demanding applications in a Laboratory T-frame freeze dryer setup.
Compact footprint, efficient design
Small lab footprint with smart layout, making this Laboratory T-frame freeze dryer suitable even for tight lab benches.
Electric defrost system
For faster cycle turnaround and ease of operation.
Advanced control system
Touchscreen + PLC, supports storage of multiple drying programs, curve display, data export-bringing modern usability to your Laboratory T-frame freeze dryer.
Technical Specifications
|
SCIENTZ-25TK |
|
|
Cold Trap Temperature (No Load) |
-80°C |
|
Ice Capacity per Batch (L/Batch) |
14L |
|
Condenser Surface Area (cm²) |
3297 |
|
Condenser Dimensions |
Ф300X350 |
|
Condensing Chamber Volume (L) |
25 |
|
Compressor Power (HP) |
1.1 |
|
Number of Compressors |
1 |
|
System Refrigerant |
R404 R23 |
|
Refrigerant Type |
Environmentally Friendly Refrigerant |
|
Defrost Method |
Electric Defrosting |
|
Average Defrost Time |
<40min |
|
Vacuum Pump |
4L/S |
|
Double-layer Horizontal Manifold Rack |
24 pcs (Wide-mouth Bottles or Pear-shaped Flasks Optional) |
|
Main Unit Dimensions |
690x750x1615mm |
|
Total Energy Consumption |
2200VA |
|
Power Supply |
220V50HZ |
Applications
- Microbial / Biotech Research:Lyophilization of bacterial, fungal cultures, spores-hanging in bottles, a classic use for a Laboratory T-frame freeze dryer.
- Peptide / Small Molecule R&D: When solvent retention, uniform drying, and traceability matter.
- Vial-style preservation:Hanging bottles with minimal contact helps maintain high sterility and integrity.
- Method development / screening: Flexibility of isolation (each bottle controlled independently) is a key advantage of a Laboratory T-frame freeze dryer.
- Educational / Pilot testing: For teaching labs, pilot project labs, or process verification using a compact Laboratory T-frame freeze dryer.
Why Choose the SCIENTZ?
- Designed for hanging bottle operations:Many freeze dryers are shelf or manifold types; the SCIENTZ-25TK is purpose-built as a Laboratory T-frame freeze dryer.
- Cross-contamination control: With independent lines and sealing valves, every sample stays isolated.
- Lab-friendly footprint:Compact layout saves space without sacrificing performance.
- Scalable upgrade path: Supports optional dual refrigeration, –80 °C trap, manifold expansions-all maintain Laboratory T-frame freeze dryer functionality.
- Proven brand & support:Backed by Scientz's deep experience in freeze-drying equipment, with global service and parts network.
Technical Support and Customization
- Full service:Installation, commissioning, operator training included.
- Warranty & maintenance:Standard 12 months, with spare parts and preventive maintenance support.
- Customization options:Alternate bottle valve styles, manifold reconfiguration, control interface upgrades, dual-compressor cooling, –80 °C trap modules, voltage variants, etc.
- Optional modules:Sample thermocouple probes, remote monitoring / SCADA, automated defrost sequencing, nitrogen charging interface.
Contact Now
If you are interested in a Laboratory T-frame freeze dryer for your R&D or microbiology lab, reach out to request a detailed quotation, technical datasheet, or to explore customization options. The SCIENTZ-25TK is ready to become your hanging-bottle freeze-drying workhorse.
